Aruba CX 6200F 24G Class-4 PoE 4SFP+ 370W Switch

The Aruba JL725B#ABA is a switch designed for teams that need reliable power and high-speed connectivity in a single rack-mountable unit. It offers 24 copper ports that supply up to 30 watts of PoE, so phones, security cameras, and Wi-Fi access points can run without separate power adapters. Four SFP+ uplink slots support either 1-gigabit or 10-gigabit connections, giving you the bandwidth to link branch sites, connect aggregation switches, or feed demanding servers.

A 1.8 GHz quad-core ARM processor works with 8 GB of DDR4 memory to keep traffic moving smoothly even when the network is busy. The fixed internal power supply provides a total PoE budget of 370 watts, which is often enough for a full stack of access points or a floor of VoIP handsets. When your organization grows, you can stack up to eight of these switches and manage them as a single logical device, saving time on configuration and troubleshooting.

The switch fits easily into a standard 1U rack space, making it a straightforward upgrade for branch offices, small campuses, or expanding businesses that want enterprise features without unnecessary complexity. Front-panel USB-C and RJ-45 console ports simplify initial setup and ongoing maintenance, whether you prefer out-of-band access or a direct serial connection.

With a switching capacity of 128 Gbps and a maximum forwarding rate of 95.2 Mpps, the Aruba JL725B#ABA keeps latency low for voice, video, and cloud-based workloads. Its combination of power, performance, and scale-out flexibility makes it a practical choice for IT teams that need to support modern devices today while leaving room for tomorrow’s growth.

• 24 Ethernet ports that each provide up to 30 W of PoE
• 4 SFP+ uplink slots supporting 1 G and 10 G links
• Stack up to 8 switches for simpler expansion
• 1.8 GHz quad-core ARM processor
• 8 GB DDR4 memory and 16 GB flash storage
• Fixed power supply with a 370 W total PoE budget
• 128 Gbps switching capacity
• 95.2 Mpps maximum throughput
• 1U rack-mountable chassis
• USB-C and RJ-45 console ports for setup and management
